M3 Corpus

M3 Corpus

The precision engineering of the M3 Corpus helps ensure improved drive performance and a more consistent driving experience for all users. This is especially true at low speeds, in tight areas, or while using a variety of alternative drive controls.

REQUEST PRODUCT INFO

M3 Sales sheets

Features

  • 3.2mph @ 12″ of Seat Elevation w/Full Suspension: Our innovative combination of swing arms, spring design and FlexLink™ Suspension enables the M3 to achieve full suspension at ANY elevation, seating position or driving speed so that you never have to sacrifice comfort for function.
  • Flexlink: Experience unsurpassed stability and comfort from our unique suspension geometry and linear spring design that is paired with our patent pending FlexLink™ Suspension for advanced vibration reduction.
  • Caster Glide: An improved 7” caster design and adjustment-free flutter dampening device means you will move more confidently at low speeds, in tight areas, or even while using a variety of alternative drive controls. You can now turn the way you want with full caster clearance even at 90º leg rest position.
  • Frame Colors: Galactic Green, Midnight Black, Ocean Blue, Radiant Red, Sunburst Orange, Power Pink, Carbon Fiber, MossyOak Breakup Country, CDG Poly Green

Specifications

  • Maximum User Weight: 300 lbs
  • Maximum Speed: 6 mph
  • Range: 13 mi
  • Base Width: 24”
  • Base Length: 35.5”
  • Minimum Turning Radius: 20.5”
  • Ground Clearance: 3”
  • Recommended Battery Type: Group 34, Group 24
  • Weight Including Batteries: 385 lbs (Gr 34), 405 lbs (Gr 24)
  • Drive Electronics: R-Net 120A
  • Seat-to-Floor Height: 17.5”, 18.5”, 19.5”
  • Optional Seat Elevator: 12”
  • Tilt Options: 0° – 50° Posterior 5º, 10° & 20° Anterior
  • Recline Options: 85° – 120° (manual), 85° – 180° (power)
  • Legrest Angle: 85° – 170°
  • Backrest Height: 20”, 23” – 28” (by 1” incr.)
  • Seat Depth: 14” – 22” (by 1” incr.)
  • Seat Width: 17” – 23” (by 2” incr.)
