• Six-wheel configuration: The addition of caster wheels reduces the turning radius and makes the NEOX more stable and easier to propel while in a tilted position.
• Adaptive design: The elongated, telescopic shapes in the NEOX frame are precision designed. The slidable tubing allows for fast, accurate positioning.
• CSF option: A Constant Seat to Floor option is available. This unique option allows to tilt the chair while keeping the knee approximately at the same height. As a result, the patient is able to propel with the feet at all angles.
• Adjustable in width, depth and height.
• Dynamic backrest: An optional dynamic backrest offers protection from uncontrolled movement and helps reduce wheelchair damage.
• Available colors: white, silver, charcoal, matte black, glossy black, starry purple, plumb, candy red, starry green, candy green, candy blue, sunset orange, yellow

Frame type: Tilt

Frame material: Aluminum

Seat depth: 14” to 22”

Seat width:

• Small frame 14” to 19”
• Extended frame 19” to 22”
• HD frame 20” to 26”

Front seat-to-floor height: 13” to 20”

Front wheel diameter: 5”, 6”, 8”

Rear wheel diameter: 12”, 16”, 20”, 22”, 24”

Transport weight:

• Neox 4 wheels 50.8 lb
• Neox 6 wheels 55.8 lb

Weight limit:

• Standard 250 lb
• Heavy Duty 350 lb
• Maximum tilt limited at 22°

Overall length: 42”

Overall width: +8” min / + 6” for 20” seat width and over

Back height: 12” to 25”

Angle adjustable back: 85° to 115°, (5° increments)

Tilt: (-) 5° to 45°

Armrest:

• « U » Type 8 ¼” to 12 ¾”
• « U » Type lowered 6” to 9”

Footrest: 60° – 70° – 90° (foldable & adjustable in height by 5” )

Legrest: elevating/articulating legrest
