Full Adjust-ability

The Tru-Fit system opens up the world of adjustability by incorporating an infinite adjustment mechanism. The Tru-Fit system allows you to fine tune the fit of your wheelchair because you are not limited to a series of pre-set holes.

Swept-In Dual-Tube Frame

Imagine no wasted energy and fewer strokes throughout the day. Then introduce your imagination to the superior rigidity and optimal energy transfer of theswept-in dual-tube frame of the TRA. Want more? Then add ease of transport to rival that of any mono-tube frame.

• The flowing lines of dual-tube geometry stiffens the wheelchair, transferring more of your push stroke directly to the ground.
• No wasted energy means fewer strokes throughout the day.
• Sweeping curve of the lower frame tube creates a unique look as the lower frame blends in and fades away.

TiFit. Personal Ergonomics

The difference between a TiFit chair and all other chairs is that a TiFit chair is a wheeled prosthetic: Every frame is made to measure. The optimized fit of a TiFit chair brings unparalleled performance and function. You will feel the difference in everything you do.

The Titanium Advantage

Titanium absorbs vibration, won’t break, and has the highest strength-to-weight ratio of any metal on Earth. That is why TiLite builds our highest performing wheelchairs from seamless, aerospace-grade titanium. If you want strength, durability, and a smooth roll, you want a titanium ride.

Frame Type*: Rigid

Frame Style*: Dual-Tube

Frame Material*: Titanium

TiFit*: YES

Adjustability*: Full Adjustability

Growable*: N/A

Custom Configuration*: YES

Frame Options:

• TRA Black Edition
• SuperLite Edition
• Power Adaptable Frame
• Reinforced Frame

Transport Weight**: 11.1 lbs.

Seat Width: 12” – 20”

Seat Depth: 12” – 20”

Front Seat Height: 15” – 21”

Rear Seat Height: 13” – 21”

Camber: 0°, 2°, 4°, 6°, 8°, 12°, 15° or 18°

Front Frame Angle: 70°, 80°, 85° or 90°

Footrest Width Options:

• Standard Taper
• V-Front End

Seat Back Type:

Folding Seat Back

Adj. Height 8.5” – 21”

Adj. Angle 80° – 101°

Center of Gravity Adjustment: 5”

Weight Limit: 265 lbs.

Transit Options: N/A

Warranty:

• Lifetime on Frame
• One Year on TiLite Components

**Weight based on 16” x 16” wheelchair with all standard features except rear wheels. Rear wheels are not included due to the varying weights of the numerous wheel configurations offered by TiLite. For reference, a pair of standard 24” (540) rear wheels weighs 7.2 lbs.
